Product Description

If you can find a lower Ranger price, let us know, We will not be undersold!

R980AT-220V TIRE CHANGER

Features & Specs

• Air Requirement 140 - 165 psi (10-11 BAR)
• Wheel Clamping Method
• 4 Clamps - Internal / External
• Table Clamping System
• Dual Pneumatic Cylinders
• Bead Breaking System
• Pneumatic Blade / Dual Settings
• Power Assist Towers
• Single Assist Tower
• Tool Holder
• Manual Lock
• Inflation Gauge With Integrated Air Dump Valve
• Inflation Pressure Regulator/Limiter
• Water Filter
• Oiler / Lubricator
• Air Regulator
• Breaker Bar
• Large Soap / Lubricator Bucket
• Brush
• Tower Design
• Rigid Fixed / Swing Arm
• Bead Lifting Roller(s)
• Single Lifting Roller
• Alloy-Steel Mount/Demount Head
• Plastic-Polymer Mount/Demount Head
• Upper Bead Assist Roller
• Traveling Drop-Center Hold Down Device
• Inflation Restraint Device
• Bead Seating System
• Turbo Blast / Bead Seating
• Tool Tray / Bin Storage
• Motorcycle Turntable Clamps (Optional)

Style

Style:

Fixed Tower Design

Assist

Assist Type:

Single-Tower Assist

Speed

Speed:

Standard

Motor

3 HP (220 VAC 50-60 HZ)

Drive System Type

Electric / Air

Air Requirement

140-165 PSI (10-11 BAR)

Wheel Clamping Method

4 Clamps - Internal / External

Table Clamping System

Dual Pneumatic Cylinders

Bead Breaking System

Pneumatic Blade / Dual

Tower Design

Rigid Fixed / Swing Arm

Power Assist Towers

Single Assist Tower

Bead Lifting Roller(s)

Single Lifting Roller

Bead Seating System

Turbo Blast / Bead Seating

Internal Rim Clamping Capacity

10” - 30” (254 mm - 762 mm)

External Rim Clamping Capacity

9” - 28” (229 mm - 711 mm)

Turntable Tire Width Capacity (Mounting)

4” - 18” (102 mm - 457 mm)

Bead Breaker Tire Width Capacity (Demounting)

1.5” - 16” (38 mm - 406 mm)

Maximum Tire Diameter

50” (1,270 mm)

Shipping Weight

904 lbs. (410 kg)

Shipping Dimensions

51'' x 45'' x 73'' (1,295 mm x 1,143 mm x 1,854 mm)

DST30P-110-220V WHEEL BALANCER

Features & Specs

• Dynamic, Static, and Performance Alloy settings
• A multi-user save function holds presets to increase productivity
• An ergonomic control board and easy-to-read LED display has vibrant visual cues and keypad to improve efficiency and proper balancing techniques for faster floor-to-floor times
• A simultaneous retrieval of static, dynamic and ALU1/ALU2 data, identifies weight placement configurations for a variety of wheel styles and designs with the simple push of a button
• Automatic rolling wheel parameter setting feature saves valuable time and minimizes errors
• Low RPM balancing speed and rapid six-second cycle time
• Automatic braking
• Gram/ounce selection and millimeter/inch selection
• Automatic round-off with top-dead-center weight position indicator
• Manual or automatic start when hood is lowered
• Self-calibration function
• High-volume top weight tray and side shelf storage gives you room to inventory a wide variety of wheel weights and tools
• Newly designed side shelf features an open-top design that accommodates Ranger Quick-Peel™ adhesive tape weight convenient bulk rolls
• Precision-machined, hardened-steel 36 mm shaft
• Quick-release hub nut for dramatically reduced set-up times
• Side-position brake hold wheels at precisely 12-o’clock for proper weight placement
• Side cone storage pegs keeps accessories readily available
• New “open-side” hood design allows for a broader coverage of tire shapes and sizes

Style

Style:

Auto & Light Truck

Data Entry

Data Entry:

Manual

Motor

1.5 HP, 110V, 50 / 60 Hz, 1Ph

Working Temperature

-5°C / 27°F - 50°C / 82°F

Cycle Time

6 - 9 Seconds (avg.)

Balancing Modes

Dynamic / Static / 3-Alloy

Drive System

Belt Drive

Wheel Braking

Automatic / Electronic

Cones Included

3 Standard / 1 Truck

Max. Tire Diameter

50” (1,270 mm)

Max. Tire Weight

150 lbs. (68 kg)

Wheel Diameter Capacity

8” - 30” (254 mm - 672 mm)

Wheel Width Capacity

1.2” - 20” (30 mm - 508 mm)

Balancing Increments

0.25 oz (7 gram)

Balancing Speed

180 RPM

Accuracy

+/- 1 gram (.035 oz)

Resolution

0.01 ounce, 1.4°

Shipping Weight

398 lbs. (181 kg)

Tape Wheel Weights

Features & Specs

• Black and silver powder-coated surface helps eliminate corrosion and staining of expensive wheels
• Strong adhesive backing for dependable attachment
• Quick-Peel™ liner for trouble-free use
• Lead-free, steel construction has less impact on the environment
• Meets national environmental laws and health and safety codes
• Designed to have same fit, function & look as OEM weights
• Narrow profile contours easier to OEM wheel shapes
• Slender profile and out-of-sight mounting capability enhance the looks of any wheel
• Low-profile design for increased clearance of close-proximity calipers or brake components
• Self-dispensing carton features Free-Glide™ center hub and nylon feeder for smooth, jam-free delivery
• Reduces inventory cost by eliminating traditional wheel weight inventories and requiring less floor space

Color

Combo (Silver & Black)

Count

700 pcs. / Roll (1,400 total)

Weight

.25 oz

Tape Width

1/2” (13 mm)

Roll Weight

11 lbs. (5 kg) / Roll

RL-8500 Lathe (GREY/YELLOW)

Features & Specs

• Precision electric DC servo motors designed to meet the demanding requirements of industrial motion control
• Quick-Change Adapter-Plus system with built-in springs eliminates the need for conventional bell clamps and cones
• Works with hubless drums, rotors (center hole sized 2-5/32" – 4") and composite rotors (center hole sized 4" – 6.25")
• The RL-8500 is equipped with features that help increase your service capability, like precision twin cutter tools and a quick drum-to-rotor changeover
• Infinitely variable spindle and cross feed speed settings allow for quick rough and precision finish cuts
• Simple ergonomic controls are designed for minimal operator movement
• Legendary control makes unit easy to learn and master
• The RL-8500 maintains accuracy year after year thanks to ruggedly constructed components like a hardened, precision ground spindle that resists grooving and makes boots a thing of the past
• Massive tapered spindle bearings offer superior weight support during rotation
• Exclusive "splash-lube" oil-feed system supplies a constant flow of oil to the bearings, making sure they provide years of trouble-free service
• Serpentine belts provide a faster, quieter operation, reducing chatter and vibration
• An independent cross feed motor eliminates the need for plastic or bronze shear gear that are expensive and time-consuming to replace
• A convenient top storage tray means your popular adapters and tools are kept within short reach
• Separate motors on the drum and rotor feed help maximize the main motor's efficiency
• Our deluxe standard adapter package includes a Quick-Change hubless adapter system that makes mounting rotors and drums quick and easy
• A variety of adapters let you machine all standard and composite rotors for foreign and domestic cars and light trucks
• A 450-lb. cast iron body and a solid work bench reduce transient vibrations, ensuring a smooth uninterrupted surface finish with each pass
• Easily change arbor speeds in seconds: choose 150 or 200 rpm, depending on the job
• Positive rake cutter tip angle provides a one-pass finish virtually every time, allowing you to complete your work faster than inferior multi-pass lathes
• Optional truck adapter kit available

Motor Drive Unit

115 – 230 VAC, 50-60 hz, 1 Ph, 20 amp

Max Rotor Thickness

2.5” (64 mm)

Max Rotor Diameter

17” (432 mm)

Brake Drum Diameter

6” – 28” (152 mm – 711 mm)

Max Load with Standard 1” Arbor

150 lbs. (68 kg)

Max Load with Optional 1-7/8” Truck Arbor

250 lbs. (113 kg)

Spindle Travel

6-7/8” (175 mm)

Spindle Speed

150 rpm – 200 rpm

Shipping Weight w/ Bench & Tools

688 lbs. (312 kg)

Shipping Dimensions

37'' x 46'' x 29'' (939 mm x 1,168 mm x 736 mm)
