Product Description
If you can find a lower Ranger price, let us know, We will not be undersold!
R980AT-220V TIRE CHANGER SPECIFICATIONS
Features & Specs
- Air Requirement 140 - 165 psi (10-11 BAR)
- Wheel Clamping Method
- 4 Clamps - Internal / External
- Table Clamping System
- Dual Pneumatic Cylinders
- Bead Breaking System
- Pneumatic Blade / Dual Settings
- Power Assist Towers
- Single Assist Tower
- Tool Holder
- Manual Lock
- Inflation Gauge With Integrated Air Dump Valve
- Inflation Pressure Regulator/Limiter
- Water Filter
- Oiler / Lubricator
- Air Regulator
- Breaker Bar
- Large Soap / Lubricator Bucket
- Brush
- Tower Design
- Rigid Fixed / Swing Arm
- Bead Lifting Roller(s)
- Single Lifting Roller
- Alloy-Steel Mount/Demount Head
- Plastic-Polymer Mount/Demount Head
- Upper Bead Assist Roller
- Traveling Drop-Center Hold Down Device
- Inflation Restraint Device
- Bead Seating System
- Turbo Blast / Bead Seating
- Tool Tray / Bin Storage
- Motorcycle Turntable Clamps (Optional)
Style
Style:
Fixed Tower Design
Assist
Assist Type:
Single-Tower Assist
Speed
Speed:
Standard
Motor
3 HP (220 VAC 50-60 HZ)
Drive System Type
Electric / Air
Air Requirement
140-165 PSI (10-11 BAR)
Wheel Clamping Method
4 Clamps - Internal / External
Table Clamping System
Dual Pneumatic Cylinders
Bead Breaking System
Pneumatic Blade / Dual
Tower Design
Rigid Fixed / Swing Arm
Power Assist Towers
Single Assist Tower
Bead Lifting Roller(s)
Single Lifting Roller
Bead Seating System
Turbo Blast / Bead Seating
Internal Rim Clamping Capacity
10” - 30” (254 mm - 762 mm)
External Rim Clamping Capacity
9” - 28” (229 mm - 711 mm)
Turntable Tire Width Capacity (Mounting)
4” - 18” (102 mm - 457 mm)
Bead Breaker Tire Width Capacity (Demounting)
1.5” - 16” (38 mm - 406 mm)
Maximum Tire Diameter
50” (1,270 mm)
Shipping Weight
904 lbs. (410 kg)
Shipping Dimensions
51'' x 45'' x 73'' (1,295 mm x 1,143 mm x 1,854 mm)
LS43B-220V WHEEL BALANCER
Features & Specs
- Dynamic, Static, and Performance Alloy settings
- Multi-user save function holds presets to increase productivity
- Ergonomic control board and easy-to-read LED display
- A simultaneous retrieval of static, dynamic and ALU1/ALU2/ALU3 data
- Automatic rolling wheel parameter setting feature saves time, minimizes errors
- Low-RPM balancing speed
- Rapid 7-second cycle time
- Automatic braking
- Gram/ounce selection and millimeter/inch selection
- Automatic round-off with top-dead-center weight position indicator
- Tiered weight placement indicators help identify out-of-sight position weight placement (such as split-weight or hidden “behind-the-spoke” techniques)
- Manual or automatic start when hood is lowered
- Self-calibration function
- High-volume top weight tray and side shelf storage gives you room to inventory a wide variety of wheel weights and tools
- Newly designed side shelf features an open-top design that accommodates Ranger Quick-Peel™ adhesive tape weight convenient bulk rolls
- Precision-machined, hardened-steel 36 mm shaft
- Quick-release hub nut for dramatically reduced set-up times
- ​Automatic brake hold wheels at precisely 12-o’-clock for proper weight placement
- Side cone storage pegs keeps accessories readily available
- “Open-side” hood design allows for a broader coverage of tire shapes and sizes
Style
Style:
Auto & Light Truck
Data Entry
Data Entry:
Automatic
Maximum tire diameter
47" (1,194 mm)
Max tire weight
145 lbs. (65 kg)
Max. wheel diameter
10" - 30" (254 mm - 672 mm)
Wheel width capacity
2" - 18" (51 mm - 457 mm)
Balancing increments
0.25 or 0.01 oz.
Balancing speed
180 RPM
Accuracy
+/- 1 gram (.035 oz.)
Working temperature
27°F (-5°C) – 82°F (50°C)
Drive system
Belt Drive
Balancing modes
Dynamic / Static / 3-Alloy
Top positioning weight locator
Standard
Inside & outside measuring
Standard
Millimeter / inches selection
Standard
Ounce / gram selection
Standard
Wheel offset distance setting
Manual
Self-calibration function
Standard
Auto start
Standard
Wheel spin braking
Automatic / Electronic
Wheel holding manual brake pedal
Standard
Centering cones included
3 Standard / 1 truck
Wheel calipers
Standard
Rear cone mount spring
Standard
No-mar rear cone mount pressure cup
Standard
Quick-release & mount hub nut
Standard
Tape Wheel Weights
Features & Specs
- Black and silver powder-coated surface helps eliminate corrosion and staining of expensive wheels
- Strong adhesive backing for dependable attachment
- Quick-Peel™ liner for trouble-free use
- Lead-free, steel construction has less impact on the environment
- Meets national environmental laws and health and safety codes
- Designed to have same fit, function & look as OEM weights
- Narrow profile contours easier to OEM wheel shapes
- Slender profile and out-of-sight mounting capability enhance the looks of any wheel
- Low-profile design for increased clearance of close-proximity calipers or brake components
- Self-dispensing carton features Free-Glide™ center hub and nylon feeder for smooth, jam-free delivery
- Reduces inventory cost by eliminating traditional wheel weight inventories and requiring less floor space
Color
Combo (Silver & Black)
Count
700 pcs. / Roll (1,400 total)
Weight
.25 oz
Tape Width
1/2” (13 mm)
Roll Weight
11 lbs. (5 kg) / Roll
